CTD Cast Details
Cast nr 2968 taken on 2013-04-23 at 51°22'37.4", 3°13'21.7"
NOTE:
The CTD casts where processed with Seasoft following the Seabird guidelines for the SBE19 and SBE19plus.
The 'flag' column in the following table is the QC flag for each scan generated during the several processing steps. The scans marked good have a flag of 0.0000e+00. Missing values are marked with -9.990e-29.
Legend
| prdM | Pressure, Strain Gauge [db] |
|---|---|
| tv290C | Temperature [ITS-90, deg C] |
| c0uS/cm | Conductivity [uS/cm] |
| obs3+ | OBS, D & A 3plus [NTU] |
| depSM | Depth [salt water, m], lat |
| sbeox0Mg/L | Oxygen, SBE 43 [mg/l] |
| sbeox0PS | Oxygen, SBE 43 [% saturation] |
| ph | pH |
| orp | Oxidation Reduction Potential [mV] |
| altM | Altimeter [m] |
| par | PAR/Irradiance, Biospherical/Licor |
| cpar | CPAR/Corrected Irradiance [%] |
| spar | SPAR/Surface Irradiance |
| nbin | number of scans per bin |
| sal00 | Salinity, Practical [PSU] |
| density00 | Density [density, Kg/m^3] |
| svCM | Sound Velocity [Chen-Millero, m/s] |
| flag | flag |
Data
| prdM | tv290C | c0uS/cm | obs3+ | depSM | sbeox0Mg/L | sbeox0PS | ph | orp | altM | par | cpar | spar | nbin | sal00 | density00 | svCM | flag |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.009 | 7.8752 | 2.9424e+04 | 157.9979 | 1.000 | 8.83849 | 90.02749 | 8.689 | 156.8729 | 4.91 | 3.8367e+02 | 4.4023e+01 | 8.7120e+02 | 9 | 27.9086 | 1021.7319 | 1473.23 | 0.0000e+00 |
| 2.017 | 7.8355 | 3.0875e+04 | 107.6123 | 2.000 | 8.93378 | 91.08627 | 8.710 | 153.9615 | 4.33 | 4.2469e+01 | 4.8730e+00 | 8.7287e+02 | 7 | 29.4653 | 1022.9623 | 1475.02 | 0.0000e+00 |
| 3.026 | 7.8027 | 3.0890e+04 | 111.2774 | 3.000 | 7.44325 | 75.82874 | 8.713 | 150.9318 | 7.42 | 3.2972e+00 | 3.7827e-01 | 8.7077e+02 | 10 | 29.5084 | 1023.0052 | 1474.97 | 0.0000e+00 |
| 4.035 | 7.7748 | 3.0781e+04 | 115.0995 | 4.000 | 7.54413 | 76.73064 | 8.714 | 149.4119 | 6.88 | 6.9723e-03 | 8.0142e-04 | 8.7110e+02 | 12 | 29.4164 | 1022.9415 | 1474.76 | 0.0000e+00 |
| 5.044 | 7.7724 | 3.0774e+04 | 114.5933 | 5.000 | 8.05518 | 81.92236 | 8.714 | 149.4316 | 6.42 | -3.478e-05 | -3.986e-06 | 8.6947e+02 | 10 | 29.4106 | 1022.9419 | 1474.76 | 0.0000e+00 |
| 6.052 | 7.7690 | 3.0772e+04 | 116.0075 | 6.000 | 7.67614 | 78.06191 | 8.714 | 149.3504 | 6.46 | 6.4202e-05 | 7.3794e-06 | 8.7007e+02 | 10 | 29.4109 | 1022.9473 | 1474.77 | 0.0000e+00 |
| 7.062 | 7.7601 | 3.0768e+04 | 122.4485 | 7.000 | 7.27286 | 73.94673 | 8.715 | 149.3553 | 5.43 | 6.9504e-05 | 8.0145e-06 | 8.6745e+02 | 11 | 29.4138 | 1022.9554 | 1474.75 | 0.0000e+00 |
| 8.070 | 7.7557 | 3.0771e+04 | 123.1162 | 8.000 | 7.41483 | 75.38635 | 8.715 | 149.3977 | 4.11 | 8.1517e-05 | 9.3840e-06 | 8.6870e+02 | 8 | 29.4202 | 1022.9657 | 1474.76 | 0.0000e+00 |
| 9.079 | 7.7207 | 3.0780e+04 | 160.8716 | 9.000 | 7.24627 | 73.63121 | 8.716 | 149.4068 | 2.80 | 8.2994e-05 | 9.5342e-06 | 8.7032e+02 | 18 | 29.4589 | 1023.0053 | 1474.69 | 0.0000e+00 |
| 8.070 | 7.7145 | 3.0772e+04 | 140.0058 | 8.000 | 7.05479 | 71.67460 | 8.716 | 149.4287 | 4.00 | 7.0591e-05 | 8.1284e-06 | 8.6848e+02 | 12 | 29.4561 | 1022.9993 | 1474.64 | 0.0000e+00 |
| 7.062 | 7.7133 | 3.0773e+04 | 129.6638 | 7.000 | 7.06470 | 71.77444 | 8.715 | 149.4102 | 4.94 | 6.3863e-05 | 7.3409e-06 | 8.7003e+02 | 10 | 29.4586 | 1022.9968 | 1474.63 | 0.0000e+00 |
| 6.052 | 7.7263 | 3.0779e+04 | 111.1408 | 6.000 | 7.04456 | 71.58964 | 8.714 | 149.3847 | 5.10 | 7.6417e-05 | 8.8095e-06 | 8.6763e+02 | 12 | 29.4544 | 1022.9871 | 1474.66 | 0.0000e+00 |
| 5.044 | 7.7638 | 3.0775e+04 | 109.6255 | 5.000 | 6.96640 | 70.83958 | 8.713 | 149.4686 | 6.72 | 2.1315e-04 | 2.4546e-05 | 8.7056e+02 | 9 | 29.4189 | 1022.9496 | 1474.74 | 0.0000e+00 |
| 4.035 | 7.7675 | 3.0773e+04 | 109.3632 | 4.000 | 6.84554 | 69.61339 | 8.712 | 149.4723 | 7.96 | 3.4774e-02 | 4.0072e-03 | 8.6688e+02 | 11 | 29.4141 | 1022.9407 | 1474.73 | 0.0000e+00 |
| 3.026 | 7.7697 | 3.0776e+04 | 112.8707 | 3.000 | 6.98174 | 71.00634 | 8.713 | 149.5063 | 8.85 | 1.1945e+00 | 1.3764e-01 | 8.6796e+02 | 9 | 29.4158 | 1022.9371 | 1474.73 | 0.0000e+00 |
| 2.018 | 7.7989 | 3.0833e+04 | 114.6905 | 2.000 | 7.34360 | 74.76738 | 8.713 | 149.5398 | 9.82 | 2.6484e+01 | 3.0573e+00 | 8.6787e+02 | 9 | 29.4518 | 1022.9567 | 1474.87 | 0.0000e+00 |
| 1.009 | 7.8993 | 3.0571e+04 | 113.5760 | 1.000 | 9.31185 | 95.10058 | 8.713 | 149.3956 | 12.24 | 4.4780e+02 | 5.1780e+01 | 8.6494e+02 | 11 | 29.0921 | 1022.6564 | 1474.79 | 0.0000e+00 |
